Parameter
| Machine parameters | Dimension | L6750*W3000*H3100mm |
| Total weight | 8400kg | |
| Engine power | 58.8KW | |
| Main motor power | 15KW | |
| Driving way | Rear wheels | |
| Traveling speed | 0-20km/h | |
| Maximum climbing degree | 30% | |
| wheelbase | 3585mm | |
| Front wheel tread | 1770mm | |
| Rear wheel tread | 1840mm | |
| Lifting height of hopper | 5640mm | |
| Rated volume of feeding hopper | 3m³ | |
| Rated volume of lifting hopper | 3m³ | |
| Rated volume of accelerator | 1000kg | |
| Hydraulic system | System working pressure | 13Mpa |
| System flow | 46.7L/min | |
| Hydraulic oil tank volume | 100L | |
| Spraying machine | Production capacity | 3×7=21m³/h |
| Maximum delivery distance（horizontal） | 200m | |
| Maximum delivery distance（vertical） | 20m | |
| Maximum aggregate diameter | 20mm | |
| Working wind pressure | 0.4~0.6 | |
| Maximum air consumption | 3×12=36m³/min | |
| Total motor power | 3×7.5=22.5KW |
